Long Range Receiver

Elsema FMR15104

Reliable & Versatile Long-Range Wireless Control

The Elsema FMR15104 4-Channel Receiver is a powerful and flexible remote control solution, designed for long-range industrial, security, and automation applications. Operating on the 151MHz frequency band, this receiver delivers stable and interference-free communication, making it ideal for gate automation, pump control, security alarms, and telemetry systems.

With four programmable relay outputs and a line-of-sight range of up to 5,000 metres, the FMR15104 ensures reliable, long-distance operation when paired with compatible Elsema FMT151 series transmitters. Its easy dip-switch setup, low power consumption, and multiple frequency selection options make it a user-friendly and highly adaptable receiver for various industrial needs.

Key Features:

• 4-Channel Relay Outputs – Supports momentary, latching, or delayed-off functions
• Wide Voltage Compatibility – Operates on 12-24V AC/DC for flexible integration
• Long-Range Operation – Works with Elsema FMT151 series transmitters, up to 5,000m range
• Narrow Band FM Signal – Ensures high frequency stability and minimal interference
• Selectable Frequency Settings – Choose from 8 different frequencies for optimal performance
• Built-In Signal Strength Indicator – Helps with installation and troubleshooting
• Easy Programming – Simple dip-switch configuration for quick setup

Optional:

• Click here for QM150 Mounting Bracket Available – For secure installation on cases or walls
• Click here for ANT151M – for extended range up to 5,000m

Ideal Applications:

• Gate Automation – Secure remote control for gates and barriers
• Pump Control – Manage water and fuel pumps remotely
• Security Alarms – Activate alarm systems from a distance
• Industrial Machinery – Control conveyors, motors, and equipment
• Long-Distance Panic Button – Emergency alert activation
• Telemetry Applications – Water level monitoring and remote automation

Upgrade your wireless control system with the Elsema FMR15104 4-Channel Receiver – a powerful, long-range, and interference-free solution for industrial automation. Order now for fast shipping!

Please note: Although this item is marked as in stock, our Elsema stock is consistently replenished to meet demand. Due to frequent bulk orders, stock levels can be challenging to determine in real-time. If you need an estimated time of arrival (ETA), please feel free to contact us, and we'll be happy to assist!

Programming Instructions

Click Here to the FMR15104 manual
